Products Description
Model No.: W11
Brand: YAOU
Material / Metal Processed: Stainless Steel
Max. Working Length (mm): 1500 Mm
Max. Plate Thickness (mm): 8 Mm
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: New Product 2020
Warranty Of Core Components: 1 Year
Core Components: Pressure Vessel
No. Of Roller: 3
Condition: New
Brand Name: Yaou
Automation: Automatic
Extra Services: Buffing / Polishing
Certification: Iso 9001:2000
Year: 2020
Machine Type: Roll Forming Machine
Key Selling Points: Multifunctional
Warranty: 1 Year
After-sales Service Provided: Video Technical Support, Overseas Service Center Available
After Warranty Service: Video Technical Support, Spare Parts
Applicable Industries: Manufacturing Plant, Machinery Repair Shops
Local Service Location: Malaysia, Uae, Bangladesh, Kyrgyzstan, Germany, India
Showroom Location: Uae, United States
Power: Cnc
Raw Material: Sheet / Plate Rolling
Color: Customized
Machinable Material: Carbon Steel, Stainless Steel
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Core Component Warranty Period: 1 Year
Number Of Rollers: 3
Old And New: New
Place Of Origin: China
Degree Of Automation: Automatic
Additional Features: Slotting &Amp; Notching
Core Selling Point: Multifunctional
Warranty Period: 1 Year
Out-of-warranty Service: Video Technical Support
Applicable Industry: Manufacturing Plant, Machinery Repair Shops
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): Uae
Showroom Location (in Which Countries Are There Sample Rooms Overseas): Uae
Rolling Speed (m/min): 2 – 20
Place Of Origin: Jiangsu, China
Weight (KG): 6000 Kg
Motor Power (kw): 3 Kw
Packaging: Export standard packaging.
Productivity: 10
Transportation: Ocean,Land
Place of Origin: CHINA
Supply Ability: 10
Certificate: ISO
HS Code: 8455109000
Port: Shanghai
Payment Type: L/C,T/T,D/P,D/A
Incoterm: FOB,CFR,CIF,EXW
- Selling Units:
- Unit
- Package Type:
- Export standard packaging.
1. Preeminence goods precision.
2. Unique curved technology, the end part of high accuracy has in advance curved, no back angle when bending continuously, curved course digital control.
3. Man-machine interaction control interface, efficient intelligent operation.
4. Man-machine interaction control interface, efficient intelligent operation.
5. Single person operation, efficient safe convenient.
6. Rich curved shape, have rolling O type,U type,multistage R and other different shapes.
7. The option of much type is made, according to use or user requirement, have economic type number to show type and the TNCtype option of numerical control….
Main Technical Data:
Specification | Pressure on The Upper Roller (Tons) | Max. PlateThickness End bending(mm) | Central(mm) | Plate Width(mm) | Diameter of The Upper Roller(mm) | Diameter of The Lower Roller(mm) | Central Distance(mm) | Motor Power (kw) Driving/Hydraulic/Shift |
W11S-8*1500 | 25 | 6 | 8 | 1500 | 175 | 125 | 160 | 3/2.2/0.75 |
W11S-8*1500 | 25 | 4.5 | 6 | 2000 | 195 | 125 | 160 | 3/2.2/0.75 |
W11S-8*1500 | 30 | 6.5 | 8.5 | 1500 | 185 | 125 | 160 | 3/2.2/0.75 |
W11S-8*1500 | 30 | 5.5 | 7.5 | 2000 | 205 | 125 | 160 | 3/2.2/0.75 |
W11S-8*1500 | 37 | 8 | 10 | 1500 | 205 | 135 | 180 | 4/2.2/0.75 |
W11S-8*1500 | 37 | 6.5 | 8.5 | 2000 | 220 | 135 | 180 | 4/2.2/0.75 |
W11S-8*1500 | 37 | 5.7 | 8 | 2500 | 235 | 135 | 180 | 4/2.2/0.75 |
W11S-8*1500 | 45 | 9 | 11 | 1500 | 215 | 135 | 180 | 4/2.2/0.75 |
W11S-8*1500 | 45 | 7.5 | 10 | 2000 | 235 | 135 | 180 | 4/2.2/0.75 |
W11S-8*1500 | 45 | 6.5 | 9 | 2500 | 245 | 135 | 180 | 4/2.2/0.75 |
W11S-8*1500 | 55 | 9 | 11 | 2000 | 245 | 145 | 200 | 5.5/4/0.75 |
W11S-8*1500 | 55 | 8 | 10.5 | 2500 | 255 | 145 | 200 | 5.5/4/0.75 |
W11S-8*1500 | 55 | 7 | 9.5 | 3000 | 275 | 145 | 200 | 5.5/4/0.75 |
W11S-8*1500 | 65 | 10 | 12 | 2000 | 250 | 145 | 200 | 5.5/4/0.75 |
W11S-8*1500 | 65 | 9 | 11.5 | 2500 | 265 | 145 | 200 | 5.5/4/0.75 |
W11S-8*1500 | 65 | 8 | 10.5 | 3000 | 280 | 145 | 200 | 5.5/4/0.75 |
W11STNC-8*1500 | W11STNC-10.5*3000 | W11ST&NC-8*1500 | W11ST&NC-10.5*3000 |
Description and specifications given in this catalogue are subject to modifivation without notice
Our supply scope has covered most products of oil/gas drilling and service:Oil Drilling Rig/worker rig,spare parts on rig ,drill handling tools, Downhole Tools .pipe line,wellhead control equipment,solid control equipment,Wellhead cement tools,fishing tools,Oil Production Tools etc,as well as accessories.We regulatethat every product which deliver to oilfield must be compliance with latest API and ISO standard ,from producing to inspection to transportation,Rugao Yaou has many techinicians to supervise and control the quality ,packing and shipment ,and feedback all information to customers at he first time.sometimes we also can provide GOST standard according to client special request.
Our company mainly deals in Hardware Tools , combined tools, electric tools, Special Tools For Petroleum, Metal Processing Machinery and petroleum drilling equipment. Diagonal Cutting Plier,Oil Drill Pipes,Drilling Tools, Diesel Engine Etc.Our companyoperates hardware tools and has established long-term and stable cooperative relations with many retailers. Rugao yaou import & Export Co. Ltd has won the trust of our customers with the principle of multi variety operation characteristics and small profit and quick turnover. Enjoy a high position among consumers.
The company provides a variety of metal Processing Machinery: shears, rolling machines, bending machines, hydraulic presses, etc.
Q1. How to get an accurate quotation?
A1: The customer should provide the related technical requirements, drawings, pictures, industrial voltage, planned output,
Q2. What if I use this machine for the first time and know nothing of it ?
A2: We will have our engineers teach you how to operate it,you can just inform us some details of the product you need then we can customize as your special order.
Q3. How does your factory do regarding quality control?
A3: We has been regard quality as the priority. We always attach great importance to quality controlling from the very beginning to the very end ,so our press can match all the CE and ISO standard also more strict standard .
Q4. How about your delivery time?
A4: Generally, it will take 35 working days after receiving your deposit payment. The specific delivery time depends on the items and the quantity of your order. Sometimes we have standard machines in stock.
Q5. What is the warrantee period of the machine?
A5: We can supply 1 year warranty for our machines, We can send engineer to customer place if big quality problem. We can provide internet or calling service at any time.
Q6. after-sales service
A6: 1. Installation:Free installation and commissioning, travel expense is on foreign customer.(Including round ticket and
accommodation cost)
2. Personnel training: Our engineers will give your employees free machine training when they come to your company to assemble the machines, and welcome to our factory to learn how to operate our machineQ1. How to get an accurate quotation?
….
