Products Description
Model No.: W11S
Brand: YAOU
Material / Metal Processed: Stainless Steel
Max. Working Length (mm): 6000 Mm
Max. Plate Thickness (mm): 100 Mm
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: New Product 2020
Warranty Of Core Components: 3 Years
Core Components: Gearbox
No. Of Roller: 3
Condition: New
Brand Name: Yaou
Automation: Automatic
Extra Services: Buffing / Polishing
Certification: Iso 9001:2000
Year: 2020
Machine Type: Roll Forming Machine
Key Selling Points: Multifunctional
Warranty: 1 Year
After-sales Service Provided: Online Support, Video Technical Support, Overseas Service Center Available
After Warranty Service: Video Technical Support, Online Support
Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Energy & Mining
Local Service Location: Malaysia, Morocco, Kenya, Uae, Kazakhstan, Ukraine, Kyrgyzstan, Uzbekistan, Tajikistan, Egypt, Turkey, United Kingdom, United States, Germany, Pakistan, India, Mexico, Russia
Showroom Location: Uzbekistan, Indonesia
Power: Cnc
Raw Material: Sheet / Plate Rolling
Machinable Material: Stainless Steel
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Core Component Warranty Period: 1 Year
Number Of Rollers: 2
Old And New: New
Place Of Origin: China
Degree Of Automation: Automatic
Additional Features: Slotting &Amp; Notching
Core Selling Point: Multifunctional
Warranty Period: 1 Year
Out-of-warranty Service: Video Technical Support
Applicable Industry: Manufacturing Plant, Machinery Repair Shops
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): United States, Ukraine, Uae, Mexico, Algeria, Uzbekistan, Tajikistan, India, Kazakhstan, United Kingdom, Turkey
Showroom Location (in Which Countries Are There Sample Rooms Overseas): Turkey, Mexico, Italy, Chile, Uae, Viet Nam, Australia, Kenya, South Africa
Rolling Speed (m/min): 20 – 50
Place Of Origin: Jiangsu, China
Weight (KG): 4800 Kg
Motor Power (kw): 75 Kw
Packaging: Export standard packaging.
Productivity: 10
Transportation: Ocean,Land,Air
Place of Origin: CHINA
Supply Ability: 10
Certificate: ISO
HS Code: 8455109000
Port: shanghai
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
- Selling Units:
- Set/Sets
- Package Type:
- Export standard packaging.
1. Preeminence goods precision.
2. Unique curved technology, the end part of high accuracy has in advance curved, no back angle when bending continuously, curved
course digital control.
3. Man-machine interaction control interface, efficient intelligent operation.
4. Man-machine interaction control interface, efficient intelligent operation.
5. Single person operation, efficient safe convenient.
6. Rich curved shape, have rolling O type,U type,multistage R and other different shapes….
7. The option of much type is made, according to use or user requirement, have economic type number to show type and the TNCtype
option of numerical control.
|
Specification
|
Pressure on The
|
Max. Plate
|
|
Plate
|
Diameter of The Upper
|
Diameter of The Lower
|
Central Distance
|
Motor Power(kw)
|
|
|
Upper Roller
|
Thickness
|
|
Width
|
Roller
|
Roller
|
(mm)
|
|
|
|
(Tons)
|
End
|
Central
|
(mm)
|
(mm)
|
(mm)
|
|
Driving / Hydraulic / Shift
|
|
|
|
Bending
|
(mm)
|
|
|
|
|
|
|
|
|
(mm)
|
|
|
|
|
|
|
|
W11S-45*3000
|
540
|
40
|
45
|
3000
|
590
|
340
|
610
|
55/22/11
|
|
W11S-40*4000
|
540
|
35
|
40
|
4000
|
630
|
340
|
610
|
55/22/11
|
|
W11S-36*5000
|
540
|
30
|
36
|
5000
|
670
|
340
|
610
|
55/22/15
|
|
W11S-32*6000
|
540
|
28
|
32
|
6000
|
700
|
340
|
610
|
55/22/15
|
|
W11S-55*3000
|
610
|
45
|
55
|
3000
|
620
|
360
|
650
|
75/30/15
|
|
W11S-45*4000
|
610
|
40
|
45
|
4000
|
660
|
360
|
650
|
75/30/15
|
|
W11S-40*5000
|
610
|
32
|
40
|
5000
|
700
|
360
|
650
|
75/30/15
|
|
W11S-36*6000
|
610
|
30
|
36
|
6000
|
730
|
360
|
650
|
75/30/15
|
|
W11S-60*3000
|
690
|
50
|
60
|
3000
|
650
|
380
|
700
|
75/30/15
|
|
W11S-50*4000
|
690
|
45
|
50
|
4000
|
700
|
380
|
700
|
75/30/15
|
|
W11S-45*5000
|
690
|
38
|
45
|
5000
|
740
|
380
|
700
|
75/30/15
|
Transportation is based on customers in different regions using steam, rail, road and air transportation.
A1: The customer should provide the related technical requirements, drawings, pictures, industrial voltage, planned output,
Q2. What if I use this machine for the first time and know nothing of it ?
A2: We will have our engineers teach you how to operate it,you can just inform us some details of the product you need then we can customize as your special order.
Q3. How does your factory do regarding quality control?
A3: We has been regard quality as the priority. We always attach great importance to quality controlling from the very beginning to the very end ,so our press can match all the CE and ISO standard also more strict standard .
Q4. How about your delivery time?
A4: Generally, it will take 35 working days after receiving your deposit payment. The specific delivery time depends on the items and the quantity of your order. Sometimes we have standard machines in stock.
Q5. What is the warrantee period of the machine?
A5: We can supply 1 year warranty for our machines, We can send engineer to customer place if big quality problem. We can provide internet or calling service at any time.
Q6. after-sales service
A6: 1. Installation:Free installation and commissioning, travel expense is on foreign customer.(Including round ticket and
accommodation cost)
2. Personnel training: Our engineers will give your employees free machine training when they come to your company to assemble the machines, and welcome to our factory to learn how to operate our machineQ1. How to get an accurate quotation?.
